EVH - Striped Series Frankenstein™ Frankie- Maple Fingerboard- Red with Black Stripes Relic

Widely regarded as the most recognizable electric guitar ever, Eddie Van Halen's iconic and revered Frankenstein™ guitar now comes your way with a price tag the everyday musician can afford in the form of the EVH® Striped Series Frankenstein™ 'Frankie.'

Sporting Eddie's famed red with white-and-black-striped paint job and a worn-in reliced look, the all-new Frankie features a basswood Stratocaster®-style body paired to a graphite-reinforced quartersawn maple neck. An oiled finish on the back of the neck allows for hours of playing comfort, while the 12'-16' compound radius maple fingerboard with 22 jumbo frets was designed for fast and furious playing styles.

Routed for an HSS pickup configuration just like Eddie's original, Frankie features an EVH Wolfgang® humbucking bridge pickup with a dummy Strat® neck pickup and a dummy five-way blade housed in the middle position.

A sturdy and dependable EVH-branded Floyd Rose® locking trem and Floyd Rose locking nut work in tandem for precise tuning even with extreme changes in pitch, while the EVH D-Tuna® retunes to drop-D and back with strict accuracy at the flick of a finger.

Other unique features include a white skirted Strat-style single volume control knob (labeled 'tone'), custom black pickguard, reliced chrome hardware, standard strap buttons and EVH neck plate.

• 25.5' scale length
• Basswood Strat®-style body
• Graphite-reinforced bolt-on quartersawn maple neck with an oiled finish on the back and licensed Fender® Strat natural headstock
• 12'-16' compound radius maple fingerboard with 22 jumbo frets and black dot inlays
• Direct mount EVH® Wolfgang® humbucking bridge pickup, dummy Strat neck pickup and a dummy five-way blade housed in the middle pickup position
• EVH-branded Floyd Rose® locking trem and locking nut
• EVH D-Tuna®
• Skirted Strat-style volume knob that reads 'tone'
• EVH-branded neck plate and standard strap buttons
• Black custom Frankie pickguard
• Available in a reliced Red with Black and White Stripes finish with reliced chrome hardware

General





SERIES

Striped Series

ORIENTATION

Right-Hand

COLOR

Red with Black Stripes Relic

COUNTRY OF ORIGIN

MX





Neck

HEADSTOCK

Licensed Fender® Stratocaster®

NECK MATERIAL

Quartersawn Maple

NECK FINISH

Oiled

NECK SHAPE

EVH® Modified 'C' Backshape

NECK CONSTRUCTION

Bolt-On with Graphite Reinforcement

NECK THICKNESS

.790' at 3rd fret & .825' at 12th fret

FINGERBOARD RADIUS

12'-16' Compound Radius (304.8 mm to 406.4 mm)

FINGERBOARD MATERIAL

Maple

POSITION INLAYS

Black Dot

NUMBER OF FRETS

22

TRUSS ROD

Two-Way Adjustable

TRUSS ROD NUT

Heel-Mount Truss Rod Adjustment Wheel

STRING NUT

Floyd Rose® R3 Locking

NUT WIDTH

1.6875' (42.86 mm)

NUT MATERIAL

Floyd Rose® R3 Locking





Body

BODY

Basswood

BODY FINISH

Satin Lacquer

BODY SHAPE

Stratocaster®

BODY MATERIAL

Basswood





Hardware

BRIDGE

EVH®-Branded Floyd Rose® Locking Tremolo with EVH® D-Tuna®

TREMOLO BLOCK

Brass

PICKGUARD

Black Custom Frankie

PICKUP COVERS

Black

CONTROL KNOBS

Parchment Stratocaster®-Style Skirt (Labeled 'Tone')

HARDWARE FINISH

Chrome Relic

TUNING MACHINES

EVH®-Branded Gotoh®

STRING TREES

Floyd Rose® Retainer Bar

STRINGS

EVH® Nickel Plated Steel (.009-.042 Gauges)

TREMOLO ARM

Floyd Rose® 1000 Series Locking

NECK PLATE

4-Bolt Standard

STRAP BUTTONS

Oversized





Electronics

BRIDGE PICKUP

Direct Mount EVH® Wolfgang® Humbucking

MIDDLE PICKUP

N/A

NECK PICKUP

Dummy Strat® Pickup

PICKUP CONFIGURATION

HSS

CONTROLS

Volume

SWITCHING

Dummy Five-Way Blade





Measurements

DIMENSIONS

4.50x15.20x42.10 IN

SHIPPING WEIGHT

11.45 LB

FRET SIZE

Jumbo

SCALE LENGTH

25.5' (64.77 cm)

SHIPPING LENGTH

42.10 IN

SHIPPING HEIGHT

4.50 IN

SHIPPING WIDTH

15.20 IN





Accessories

INCLUDED ACCESSORIES

Tremolo Arm, Hex Keys & User Manual

TRUSS ROD WRENCH

2.5 mm Hex





Miscellaneous

COMMODITY CODE

9207901000
