Audio-Technica - AT-PEQ30 Phono Equalizer
Audio - Technica - Égaliseur phono AT - PEQ30 - La Boîte Musicale - Preamp - Audio - Technica -
Audio - Technica - Égaliseur phono AT - PEQ30 - La Boîte Musicale - Preamp - Audio - Technica -
Audio - Technica - Égaliseur phono AT - PEQ30 - La Boîte Musicale - Preamp - Audio - Technica -
Audio-Technica

Audio-Technica - AT-PEQ30 Phono Equalizer

SKU: AT-PEQ30
Sale price$319.00
Out of stock | Pre-Order available Usually 1-2 weeks or you will be contacted by one of our sales representative.
More information

The AT-PEQ30 phono equalizer is designed to add a phono stage to a turntable system or upgrade a turntable's built-in phono preamp.

It is compatible with turntables using MM (Moving Magnet) and MC (Moving Coil) cartridges. The AT-PEQ30 draws on Audio-Technica's years of analog audio expertise, using high-quality components in a configuration optimized for low noise and minimal distortion.

Description

  • Selectable MM and MC inputs with fixed gain and impedance make the unit compatible with a wide range of moving-magnet and moving-coil cartridges

  • High-quality FET inputs ensure a low-noise signal when the unit is integrated into a feedback phono equalizer circuit

  • High-precision components provide excellent RIAA response for outstanding phono equalizer performance

  • The all-metal housing provides effective isolation from radio interference and electronic noise

  • The machined aluminum front panel and gold-plated RCA input and output connectors are examples of the high-quality materials used in this model
  • Phono Equalizer
    Input impedance Type MM : 47 kiloohms Type MC : 120 ohms
    Input sensitivity Type MM : 4,5 mV Type MC : 0,28 mV
    Nominal output Type MM : 250 mV Type MC : 250 mV
    Gain Type MM : 35 dB Type MC : 59 dB
    Signal-to-noise ratio Type MM : 100 dB Type MC : 74 dB
    RIAA deviation (from 20 to 20 000 Hz) MM type: ±0,5 dB (from 20 to 20 000 Hz) MC type: ±0,5 dB
    Power supply DC 15 V, 1,2 A
    Power consumption 2,5 W
    Dimensions 47 mm (H) × 197,5 mm (W) × 125,5 mm (D) (excluding protrusions)
    Weight 890 g
    Included accessories AC adapter
Audio-Technica - AT-PEQ30 Phono Equalizer
Audio-Technica - AT-PEQ30 Phono Equalizer Sale price$319.00
