Marshall - 20W JTM Valve Head

The amp that started it all is back. The same iconic JTM sound, but more compact packing the power you know and love from Marshall, in a new compact size. The JTM is a welcome addition to the Studio range, offering players authentic, smooth, and valve-driven break-up at lower volumes – perfect for home or studio use. Don’t let its size fool you, the superb allvalve tone of the Studio JTM packs a punch. Creating a sound that defined a generation the JTM delivers the legendary loud blend of crunch and clean recognised the world over. Like the original 30W head, the Studio JTM is loaded with two ECC83 preamp valves, two 5881 power amp valves and one ECC83 phase splitter, taking you right back to the renaissance of rock’n’roll. The Studio JTM offers the same control and versatility as older models, where simply patching the two channels together opens up a world of all-valve tonal possibility. Power switching enables you to switch effortlessly between 20W and 5W and two loudness controls mean you can play as loud as you like. Features such as a DI out and FX loop have been added, bringing the JTM into the now. Hand built at our world-class factory in Bletchley, England, the Studio JTM features fingerjointed cabinets, hand-welded chassis, hand-soldered potentiometers and valve bases, and the highest quality componentry. Adorned with period-correct aesthetics from the same metal, red enamel poured “coffin” logo to its fawn fret complete with gold piping and beading, the Studio JTM beautifully nods to the 60s.
Power: 20W with power reduction to 5W 2 x ECC83, 1 x ECC83 (phase splitter) and 2 x 5881
Valves: Single channel with four separate inputs
Channels: High treble and normal loudness controls
Equalisation: Treble, middle, bass and presence
Speaker outputs: 5 x 1/4” jack sockets (16O load / 8O load / 4O load)
Outputs: DI output
Unit weight: 9.25kg
Unit width: 500mm
Unit height: 240mm
Unit depth: 230mm
